Category: Industrial Valve Series
Description:
Technical Standard Design Standard：GB/T12237、API6D、BS5351
Pressure-Temperature Rating:GB/T12224、ASME B 16.34
Face To Face Std：GB/T12221、ASMEI B 16.10、BS4460、DIN3202
End Flanged Std:GB9113、JB79、ASME B 16.5a、DIN2543-2546、BS4504、JISB2213-2216
Test Standard:GB/T13927、ISO5208、API598、API6D
Material：WCB、A105、CF8(304)、CF8M(316)
Operated Way:Handle、Gearcase、Actuator、Electric
| Follow Us: |  |
 |
 |
 |
 |
3pc Floating Ball Valve
DIMENSIONS
| Item Size | 1/2" | 3/4" | 1" | 11/4" | 11/2" | 2" | 21/2" | 3" | 4" |
| D | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
| D1 | 45 | 58 | 68 | 78 | 88 | 102 | 122 | 138 | 158 |
| D2 | 65 | 75 | 85 | 100 | 110 | 125 | 145 | 160 | 180 |
| D3 | 95 | 105 | 115 | 140 | 150 | 165 | 185 | 200 | 220 |
| n-d | 4-14 | 4-14 | 4-14 | 4-18 | 4-18 | 4-18 | 4-18 | 8-18 | 8-18 |
| T | 14 | 14 | 14 | 16 | 19 | 20 | 20 | 22 | 22 |
| f | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| L | 130 | 150 | 160 | 180 | 200 | 230 | 290 | 310 | 350 |
| H | 55 | 60 | 70 | 85 | 90 | 110 | 115 | 145 | 155 |
| E | 102 | 120 | 140 | 161 | 180 | 180 | 215 | 240 | 300 |
| Size Range | DN | 15-200mm | |
| Working Pressure | DN | 1.6-6.4Mpa、150-300LB、10K、20K | |
| Suitable Temperature | （-29-200°C） | ||
| Suitable Medium | CF8304：Nitric acid | CF8M316：Acetic acid | Water、Natural gas、Oil |
