Category: Industrial Valve Series
Description:
Technical Standard Design Standard：GB/T12224、GB/T8464
Pressure-Temperature Rating:GB/T12224
Test Standard:GB/T13927
Material：WCB、CF8(304)、CF8M(316)
Operated Way:Handle
| Follow Us: |  |
 |
 |
 |
 |
3pc Welded Ball Valve With Connection
DIMENSIONS
| Item Size | 1/4" | 3/8" | 1/2" | 3/4" | 1" | 11/4" | 11/2" | 2" |
| D | 11.6 | 12.7 | 15 | 20 | 25 | 32 | 40 | 50 |
| L | 150 | 150 | 180 | 195 | 210 | 225 | 260 | 300 |
| H | 48 | 48 | 54 | 57 | 72 | 79 | 81 | 97 |
| E | 120 | 120 | 120 | 130 | 154 | 154 | 185 | 185 |
| D | 14 | 14 | 21 | 26 | 31 | 38 | 46 | 60 |
| Size Range | DN | 15-200mm | |
| Working Pressure | DN | 1.6-6.4Mpa、150-300LB、10K、20K | |
| Suitable Temperature | （-29-200°C） | ||
| Suitable Medium | CF8304：Nitric acid | CF8M316：Acetic acid | Water、Natural gas、Oil |
